Standard Multi-Weigher

ELC Standard 10 & 14 Head Multi-Weighers

Our weighers are used in a wide variety of foods: Chips, Nuts, Cookies, Candies, Pasta, Baked Goods, Confectionary, Coffee, Pet Food, Spices & Seasonings, Fruits, Vegetables, and many more.

Product Information

Features

Extremely accurate, fast, and reliable.
Load cell accuracy to 0.1 gram.
All heavy duty 304 Stainless steel sanitary construction.
All product contact parts are easily removed with out tools for easy cleaning.
Load cell on top cone to easily control product feeding via parameters in the HMI.
10" color touchscreen (HMI).
Ready to interface with ELC Conveyor control panels. Simple to interface with other conveyors and systems.
Low pressure washdown rated.
220 Volt 60W 1 Phase Standard (other voltages and power options are available).

Options

1.6 or 2.5L buckets.
10 or 14 head models.
Timing hopper.
Positive air pressure for high pressure washdown.
Smooth or Dimpled finish for contact parts.
Too many other options to list. Contact us to help customize a weigher for your product.

Video Demonstration

10 Head Weigher Specs

Model	ELC-MWA10-1.6 (ELC-MWA10-1.6D)	ELC-MWA10-2.5 (ELC-MWA10-2.5D)
Weight Range	10-1000g
No. Weigh Heads	10
Weigh Volume	1.6L	2.5L
HMI	10" Color Touchscreen
Max Weigh Speed*	65 WPM
Preset Programs	200
Power	220V 1PH/1000W/60Hz/10A
Material	304 Stainless Steel
Finish	Smooth (Dimpled)
Price	$19,995 ($23,995)	$24,995 ($26,995)

*Actual speed depends on product flow, target weight, and the speed of the attached filling equipment.

CAD drawing of an ELC 10 Head Weigher with a Timing Hopper

14 Head Weigher Specs

Model	ELC-MWA14-1.6 (ELC-MWA14-1.6D)	ELC-MWA14-2.5 (ELC-MWA14-2.5D)
Weight Range	10-1500g
No. Weigh Heads	14
Weigh Volume	1.6L	2.5L
HMI	10" Color Touchscreen
Max Weigh Speed*	120 WPM
Preset Programs	200
Power	220V 1PH/1500W/60Hz/10A (Dedicated Breaker)
Material	304 Stainless Steel
Finish	Smooth (Dimpled)
Price	$36,950 ($37,950)	$38,950 ($39,950)
